EVCE-SV2-10-2NO

Technical Specifications

Operating Pressure :207Bar

Flow：68L/min

Internal leakage：2 drops/min at 207bar

Operating temperature :-30°C to+ 120°C(-22°F to+ 250°F)

Cavity :VC10-2

Fluids:Mineral based or synthetic hydraulic fluid with lubricating properties

Fluid viscosity range:7.4 to 420cSt.

Features

Hardened seat for long life

Compact size

Industry common cavity

Continuous-duty rated solenoid

Optional coil voltages and terminations

Operation

When de-energized, the EVCE-SV2-10-2NO allows flow from port 2 to port 1.Flow from port 1

to port 2 is severely restricted in this mode. When energized, the valves poppet closes on its

seat, blocking flow from port 2 to port 1.
