EVCF-RF10-39

Technical Specifications

Operating Pressure :240Bar

Flow：0-38L/min

Flow Rating:

Regulated,2-ported:0-34L/min

Regulated, 3-ported: 0-38L/min

Inlet flow rating:

Nominal,3-ported:38L/min

Maximum, 3-ported:57L/min

Internal Leakage:33cc/min(207bar)

Operating temperature :-30°C to+ 120°C(-22°F to+ 250°F)

Cavity:VC10-3

Fluids:Mineral based or synthetic hydraulic fluid with lubricating properties

Fluid viscosity range :7.4 to 420cSt.

Features

Hardened seat for long life

Compact size

Industry common cavity

Modulated response

Operation

The valve provides set regulated flow regardless of pressure variations at regulated or

bypass port. Regulated flow increases from closed to fully open with clockwise rotation

of the adjusting screw.
