EHTT

Product Description

• Operating pressure up to 500 bar
• DN up to 25
• Application in hydraulics, particularly in construction industry and agricultural machinery, mining industry
• All ball valves can be supplied with the following options: Actuator, Limit controls & Lock

Technical Specifications

Application: In-line assembly

Standard Connections Styles: Female BSP thread (DIN ISO 228)

Female NPT thread (ANSI B1.20.1)

Female UN/UNF thread (SAE J 514)

24°Cone Connection light Series (DIN 2353 / ISO 8434-1)

24°Cone Connection Heavy Series(DIN 2353 / ISO 8434-1)

Construction: Block body design

Type of construction: Shut-off device is a ball

Nominal pressure: PN 315 bar up to PN 500 bar (according to dimension table)

Operating fluids: Oils, petroliferous and petrochemical products

Operating temperature range: -20°C to 100°C

Standard Material

Body: Carbon Steel

Ball: Carbon Steel

Stem: Carbon Steel

Lever: Zinc Alloy Bent (DN 06 to 25)

Steel Straight (DN 06 to 25)

Steel Bent (DN 32 to 50)

Ball seat: POM

O-rings: NBR/FKM
