EVCE-SV08-47C

Technical Specifications

Operating Pressure :207Bar

Flow：11.4L/min

Internal leakage：164ml/min at 207bar

Operating temperature:-30°C to+ 120°C(-22°F to+ 250°F)

Cavity:VCO8-4

Fluids:Mineral based or synthetic hydraulic fluid with lubricating properties

Fluid viscosity range:7.4to 420cSt.

Features

Hardened seat for long life

Compact size

Industry common cavity

Continuous-duty rated solenoid

Optional coil voltages and terminations

Operation

When de-energized, the EVCE-SV08-47C blocks all ports. When coil 1 is energized,flowis

allowed from 3 to 4, and from 2 to 1. When coil2 is energized, flowis allowed from 3 to 2 and from 4 to 1.
