EVCE-SV2-08-2NCR

Technical Specifications

Operating Pressure :207Bar

Flow:23L/min

Internal leakage:3 drops/min at 207bar

Operating temperature:-30°C to + 120°C(-22°F t o+ 250F）

Cavity:VC08-2

Fluids:Mineral based or synthetic hydraulicfluid with lubricating properties

Fluid viscosity range:7.4 to 420cSt.

Features

Hardened seat for long life

Compact size

Industry common cavity

Continuous-duty rated solenoid

Optional coil voltages and terminations

Operation

When de-energized,the cartridge acts as acheck valve, blocking flow from port 2to port 1,

while allowing flow in the reverse direction.When energized,the valve allows flow from port

2 to port 1,Inthis mode, flowis also allowed fromport 1 toport2.
