EVCE-SV2-10-2NCR

Technical Specifications

Operating Pressure :207Bar

Flow:56.8L/min

Internal leakage：3 drops/min at 207bar

Operating temperature:-30°C  to+ 120°C(-22°F to+ 250°F)

Cavity :VC10-2

Fluids:Mineral based or synthetic hydraulic fluid with lubricating properties

Fluid viscosity range :7.4 to 420cSt.

Features

Hardened seat for long life

Compact size

Industry common cavity

Continuous-duty rated solenoid

Optional coil voltages and terminations

Operation

When de-energized,the cartridge acts as a check valve, blocking flow from port 2 to port 1,

while allowing flow in the reverse direction.When energized,the valve allows flow from port

2 to port 1,In this mode, flow is also allowed from port 1 to port 2.
