EVPC03

EVPC-03

Configure EVOTEK products according to your requirements. Go to options to see all configuration possibilities.
Clear

Description

  • CETOP03 Pressure relief valve
  • Size: ND06 –ISO 4401-03 (CETOP03)
  • Flow rate: max. 50 l/min in controlled linesmax. 75 l/min in free lines
  • Pressure: max. 350 bar
  • Ambient temperature range: -20 to 50 °C
  • Fluid temperature range: -20 to 80 °C
  • Fluid viscosity range: 10 to 400 cSt
  • Recommended viscosity: 25 cSt
  • Fluid contamination degree:according to ISO 4406: 1999 class 20/18/15
