Evotek Cartridge Check Valve

EVCC-A

Configure EVOTEK products according to your requirements. Go to options to see all configuration possibilities.
Clear

Description

  • Cartridge check valve
  • Size: G ¼”, G ⅜” & G ½”
  • Flow rate: 20, 50 & 80 l/min
  • Cracking pressure: 0.5 bar
  • Pressure: max. 350 bar
  • Fluid temperature: -30°C to 110°C
  • Viscosity: 30 to 100 mm²/s (cSt) at 40°C
  • Recommended filtration: 25 μm
  • Compatibility: Suitable for hydraulic oils in compliance with DIN51524
